Blue Sea 2356 Water Resistant BusBar - 100 Amp w/Cover [2356]

Name: Blue Sea 2356 Water Resistant BusBar - 100 Amp w/Cover [2356]
Brand: Blue Sea Systems
SKU: EM-80379
Price: 37.99 USD
Availability: InStock

$37.99 $54.99

Refund & Return Policy

Returns are accepted within 30 days after shipment. To be eligible for a return, items must be unused, uninstalled, and in their original packaging, and proof of purchase is required. Installed or used products, clearance or final-sale items are not eligible for return. Return Merchandise Authorization (RMA) numbers are required for all returns. Learn more.

Shipping Policy

Egret Marine ships marine parts and accessories within the continental United States only. Orders are processed same day if placed before 3pm CST. or within 1 business days if placed after 3pm CST, excluding weekends and holidays. Learn more.

Description

2356 Water Resistant BusBar - 100 Amp with Cover

Provides secure water-resistant bussing for harsh environments. The single side nesting design allows for wire entry from one side to maximize space.

Features:

Water-resistant design with standard ring or fork type terminals allows for simple wiring with standard tools.
Accepts a wide range of wire sizes
Includes 3 wire plugs to maintain water-resistant rating if less than 4 wires are used
Nests with other Water-Resistant 100A Common BusBars and ST-Blade Water-Resistant Fuse Block for space saving wiring
Ideal for positive distribution and for the collection of negative or AC ground circuits
Insulating cover meets ABYC/USCG insulation requirements
Tin-plated copper busses and fuse clips
Includes four write-on circuit labels
Small format standard and custom labels available

Specifications:

Cover: Yes
Maximum Voltage: 300V AC/48V DC
Continuous Rating: 100A AC/100A DC
Bus Material: Tin-Plated Copper C11000
Mounting Holes: Accepts 1/4" (6mm) Screws
Terminal Screw: 4 x #8-32
Terminal Stud: 1 x #10-32
Wire Size: (1) 8 AWG to 4 AWG - Input/(4) 16 AWG to 10 AWG - Load
