Uflex USA  |  SKU: EM-77782  |  Barcode: 702755060680

Uflex Mechanical Hatchlifter 12" STK Fast [AV3012]

$699.99 $842.10

SHIPS SAME DAY BEFORE 3PM CST! Shipping Policy

Refund & Return Policy

Returns are accepted within 30 days after shipment. To be eligible for a return, items must be unused, uninstalled, and in their original packaging, and proof of purchase is required. The following items are not eligible for return: Installed or used products, clearance or final-sale items, trolling motors, programmed AIS units, KVH Starlink products that are registered or opened, special-order products, or products displaying the notice “This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.” in their description. Opened or unsealed DVDs, CDs, or cartography (unless defective) are not eligible for return. Return Merchandise Authorization (RMA) numbers are required for all returns. Learn more.

Shipping Policy

Egret Marine ships marine parts and accessories within the contiguous United States only. Orders are typically processed same day if placed before 3pm CST, excluding weekends and holidays. Learn more.

Product Details

Mechanical Hatchlifter 12" STK Fast

The AV hatch lifters are electromechanical products, especially designed for marine use on pleasure boats. They allow full or partial opening and closing of heavy engine hatches, peak tanks, hatch beams etc. By activating a switch, it is possible to lift the hatch to any desired position from closed to full open; an internal self-locking mechanism will maintain the position preventing any accidental hatch closing. In case of a power failure, an emergency device allows for manual opening.

The Uflex AV hatch lifters do not require any maintenance, are easy to install, and are made of materials resistant.

Features:

  • According to the load required, the AV hatch lifter can be mounted individually, or in twin-cylinder installations for heavier loads. It is also possible to install more than two AV actuators in multiple applications.
  • Maximum load for single installations: 1200N (120 kg - 265 lbs)
  • Maximum load for dual installations: 2400N (240 kg - 529 lbs)
  • Maximum load is recommended not to be exceeded.
  • Supplied with all mounting hardware.
  • Stainless steel telescopic ram for manual operation in case of emergency.
  • Available on request without a manual emergency opening device for high-performance boats.
  • Circuit breaker to stop accidental overloading of the system and electronic stop at the closed or fully open position.
  • IP 65 protection rated
  • Speed: 25mm/sec no load applied, 17 mm/sec maximum load
  • Current absorption in single installations: 10A at 12V, 5A at 24V
  • Current absorption in dual installations: 20A at 12V, 10A at 24V
  • AV 12VDC models are Ignition Protected. UL1500 - ISO8846 approved.

Specifications:

  • Volt: 12V DC
  • Stroke: 300mm (12")
  • Length A (full closed actuator): 677 mm (26.6")
  • Ø External: 48 mm (1.9")
