DS18  |  SKU: EM-104340  |  Barcode: 810097261907

DS18 NXL-M5 Full Range 5 Channel Class D Amplifier - 4 x 150W @ 4-Ohm 1 x 600W RMS @ 2-Ohm [NXL-M5]

Regular price $719.95

SHIPS SAME DAY BEFORE 3PM CST! Shipping Policy


Refund & Return Policy

Returns are accepted within 30 days after shipment. To be eligible for a return, items must be unused, uninstalled, and in their original packaging, and proof of purchase is required. The following items are not eligible for return: Installed or used products, clearance or final-sale items, trolling motors, programmed AIS units, KVH Starlink products that are registered or opened, special-order products, or products displaying the notice “This product may not be returned to the original point of purchase. Please contact the manufacturer directly with any issues or concerns.” in their description. Opened or unsealed DVDs, CDs, or cartography (unless defective) are not eligible for return. Return Merchandise Authorization (RMA) numbers are required for all returns. Learn more.

Shipping Policy

Egret Marine ships marine parts and accessories within the contiguous United States only. Orders are typically processed same day if placed before 3pm CST, excluding weekends and holidays. Learn more.


Product Details

NXL-M5 Full Range 5 Channel Class D Amplifier - 4 x 150W @ 4-Ohm & 1 x 600W RMS @ 2-Ohm

DS18’s NXL-M5 is a full-range marine amplifier that combines cutting-edge technology, unmatched durability, and mind-blowing sound quality. Utilizing an impressive MAX power of 3600W, the NXL-M5 delivers unrivaled performance that will make a system soar. With its RMS power output of 4 x 150W and a whopping 600W for SUBs, the NXL-M5 guarantees consistent audio performance that is guaranteed to satisfy even the most discerning audiophile. The DS18 NXL-M5 covers the full range of frequencies, ensuring that every beat, note, and whisper is reproduced with unrivaled precision.

Features:

  • Marine full range
  • 5 channel
  • 4 x 150 Watts @ 4 Ohm + 1 x 600 Watts @ 2 Ohm
  • Built-in crossover
  • Class D
  • Water-resistant IPX5

Technical Specifications:

  • Number of Channels: 5
  • Frequency Response: 20Hz - 20KHz
  • 2 Ohm RMS Power Per Channel: 4 x 230W / SUB: 600W
  • 4 Ohm RMS Power Per Channel: 4 x 150W / SUB: 300W
  • 4 Ohm RMS Power Bridge Channel: 2 x 440W
  • Signal-to-Noise Ratio: >90dB
  • Product Dimensions: (L x W x H): 14.3" x 4.5" x 1.7"

Specifications:

  • Bridgeable: Yes
  • Channels - Available: 5
  • Waterproof Rating: Splashproof
  • Watts: 4 x 150w
  • Box Dimensions: 3"H x 6"W x 18"L WT: 5.6 lbs
  • UPC: 810097261907
